FM-YL1100

FM-YL1100 Medical Package Coating Flexo Printer

Medical Package Coating Flexo Printer with multi-colour printing on the front side of the sheet and high register accuracy. Large drying unit on top.

Supports multiple drying methods.

Fastest production speed 150m/min.

Machine energy saving 30%.

Request an inquiry Download

Medical Package Frame Coating Flexo Printer

Applications Description Parameters Details Related machinery

Product Applications

Medical grade packaging

Sample

Product Description

Main Characteristics

Medical Package Coating Flexo Printer is mainly used in the medical industry packaging and glue coating, such as disposable sterile rubber surgical gloves, front of paper with mufti-color printing, high precision of registration, backside of paper with frame glue coating, large drying unit is on the top. This machine is high speed, energy saving and environmentally-friendly.

1. The printing precision is extremely high, which can ensure that the printed patterns, texts and other information are clear and accurate

2. It has multiple printing modes and functions, such as monochrome and multi-color printing, etc.

3. Every link meets the hygiene and safety requirements of the medical industry

4. It has complete safety protection measures, such as anti-static and fire prevention, etc.

5. The operation interface is usually simple and clear, and easy to use.

Product Parameters

Specification	1100
Max.Web width	1120mm
Max.Printing width	1100mm
Max.Glue coating width	1100mm
Printing repeat length	286-1200mm
Max.Unwinder diameter	1524mm
Max.Rewinder diameter	1524mm
Max.Mechanical speed	150m/min
Base motor power	11KW
Drying mode	a.Hot air drying b.lR drying
Applicable ink	a.Water-basedink b.UV ink
Power reguirement	380V 3PH 50HZ

Note: as the products are developing day by day, the technical data are subject to change without notice

Product Details

CCD camera

Cylinder

Iron casting

Position conroller

Servo

Unwinder

Web guide
