How does a non-plastic coating machine work

In the current era that emphasizes environmental protection and sustainable development, the Non-plastic coating machine, as an important industrial equipment, plays a crucial role in numerous fields. It can conduct efficient and precise coating operations on various materials without using plastic, which not only meets the functional requirements of products but also complies with environmental protection requirements. Understanding its working principle is of great significance for better operating and maintaining the equipment and improving production efficiency and product quality.

Working Principle of the Non-plastic Coating Machine
Coating Material Supply System: Firstly, the Non-plastic coating machine needs to transport specific non-plastic coating materials from storage containers to coating heads or rollers and other coating components. This process is usually completed by high-precision metering pumps or feeding devices to ensure the stability and accuracy of the coating material supply. Depending on the properties of different coating materials and coating requirements, the supply system may also be equipped with stirring devices, heating devices, or filtering devices, etc. For example, for some water-based coatings, they may need to be heated to a certain temperature to reduce their viscosity and improve the smoothness of coating; while for coatings containing particles, filtering devices are required to remove impurities and prevent clogging of the coating heads.

Coating Heads or Rollers: After the coating materials reach the coating heads or rollers, they are evenly coated onto the surface of the materials to be processed through these components. Common coating methods include roll coating, knife coating, air knife coating, and gravure coating, etc.

Roll Coating: The surface of the coating roller is usually made of special materials such as rubber, silica gel, or fluoroplastics to meet the requirements for adhering to and transferring the coating materials. When the material to be coated passes by the coating roller, the coating material adheres evenly to the surface of the material under the rotation and pressure of the roller. By adjusting parameters such as the pressure between the coating roller and the material, the rotation speed of the roller, and the viscosity of the coating material, the thickness and uniformity of the coating can be controlled.

Knife Coating: The doctor blade maintains a certain gap with the coating roller or the surface of the material. The coating material is evenly scraped and coated onto the material under the action of the blade. Factors such as the angle, pressure of the blade, and the distance from the coating component will affect the coating effect and can be precisely adjusted according to actual needs.

Air Knife Coating: High-speed air flow is used to blow the coating material towards the surface of the material, so that the coating material spreads and adheres evenly under the action of the air flow. Air knife coating can achieve a relatively high coating speed and good coating uniformity, and is suitable for the production needs of large-area and high-speed coating.

Gravure Coating: Coating is carried out through a coating roller with a specific gravure pattern. The coating material is stored and transferred in the cells of the gravure roller. When the gravure roller contacts the material, the coating material is transferred to the surface of the material to form a uniform coating. The number of lines per inch and the shape of the cells of the gravure roller determine the coating amount and coating effect, and an appropriate gravure roller can be selected according to different coating requirements.

Drying and Curing System: After the coating is completed, in order to make the coating form a firm and stable layer on the surface of the material, the coated material needs to be dried and cured. The drying and curing system usually adopts methods such as hot air circulation, infrared radiation, and ultraviolet irradiation. The appropriate drying method is selected according to the properties of the coating material and the drying requirements. For example, for water-based coatings, hot air circulation drying is generally adopted. The heated air is circulated in the oven to take away the moisture in the coating material and accelerate the drying and curing of the coating material; while for some light-curing coatings, ultraviolet irradiation is used to make the coating material solidify rapidly within a short time, improving production efficiency.

Control System: The control system of the Non-plastic coating machine is the core to ensure the precise and stable operation of the entire coating process. It monitors and precisely controls the coating material supply, coating process, and drying and curing processes in real time through sensors, controllers, and actuators. Sensors can detect parameters such as the flow rate, pressure, and temperature of the coating material, as well as the running speed and tension of the material, and transmit these data to the controllers. The controllers automatically adjust parameters such as the coating material supply amount, coating speed, and drying temperature according to the preset coating parameters and the information fed back by the sensors to ensure the consistency and stability of the coating quality. Meanwhile, the control system can also realize the functions of automated operation and fault diagnosis of the equipment, improving production efficiency and the reliability of the equipment.
